| Category | Feature | Details |
|---|---|---|
| News & Updates | Release Date | 2024/10/24 |
| Update Info | A new BIOS has been released addressing various bugs, including no display from the graphics card when installing Windows 11 24H2. | |
| Update Method | Recommended to use the new EZ Flash tool to update directly using the ZIP file downloaded from the ASUS site. | |
| CPU | Socket | Intel® Socket LGA1851 for Intel® Core™ Ultra Processors (Series 2) |
| Turbo Boost Technology | Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0 | |
| Support Link | CPU Support List | |
| Chipset | Chipset | Intel® Z890 Chipset |
| Memory | DIMM Slots | 4 x DIMM slots, max. 192GB, DDR5 |
| Memory Speed | Supports up to 8600+MT/s (OC), Non-ECC, Clocked Unbuffered DIMM (CUDIMM) | |
| Architecture | Dual Channel Memory Architecture | |
| Support Features | Supports Intel® Extreme Memory Profile (XMP), DIMM Flex, DIMM Fit, ASUS Enhanced Memory Profile III (AEMP III) | |
| Non-ECC Feature | Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function | |
| Graphics | Display Outputs | 1 x DisplayPort, 1 x HDMI® port, 2 x Intel® Thunderbolt™ 4 support DisplayPort and Thunderbolt™ video outputs |
| Display Resolution | Supports max. 8K@60Hz (DisplayPort 1.4) and 4K@60Hz (HDMI 2.1) | |
| Notes | Ensure monitor is connected to HDMI or a discrete graphics card during OS installation. | |
| Expansion Slots | PCIe Slots | 1 x PCIe 5.0 x16 slot (supports x16 or x8/x4/x4 modes), 1 x PCIe 4.0 x16 slot (supports x4 mode) |
| Compatibility Link | PCIe Bifurcation Table | |
| Device Compatibility | Please refer to ASUS support for a list of supported peripherals. | |
| Storage | M.2 and SATA Ports | Supports 5 x M.2 slots and 4 x SATA 6Gb/s ports |
| M.2 Slot Configuration | M.2_1 (PCIe 5.0 x4), M.2_2 (PCIe 4.0 x4), M.2_3 (PCIe 4.0 x4), M.2_4 (PCIe 4.0 x4), M.2_5 (PCIe 4.0 x4 & SATA modes) | |
| RAID Support | Intel® Rapid Storage Technology supports PCIe RAID 0/1/5, SATA RAID 0/1/5/10, M.2 slots from CPU only support RAID 0/1/5. | |
| Notes | For supported memory types and configurations, refer to CPU/Memory Support list on ASUS site. | |
| Drive Types | 4 x SATA 6Gb/s ports | |
| Ethernet | Ethernet Port | 1 x Intel® 2.5Gb Ethernet |
| Features | ASUS LANGuard | |
| Wireless & Bluetooth | Wi-Fi Standard | Wi-Fi 7 (802.11be), Supports 2.4/5/6GHz frequency bands |
| Bandwidth | Supports Wi-Fi 7 320MHz bandwidth, up to 5.8Gbps transfer rate | |
| Bluetooth Version | Bluetooth® v5.4 | |
| OS Compatibility | For Windows 11, Wi-Fi 7 requires 24H2 or later. Windows 10 supports only Wi-Fi 6. | |
| USB Ports | Rear USB Ports | 2 x Thunderbolt™ 4, 6 x USB 10Gbps (4 x Type-A + 2 x Type-C), 4 x USB 5Gbps, 2 x USB 2.0 |
| Front USB Ports | 1 x USB 20Gbps, 2 x USB 5Gbps headers (4 additional ports), 2 x USB 2.0 headers (4 additional ports) | |
| Power Delivery | USB Type-C® power delivery outputs: 5V/3A, up to 30W Fast-charge | |
| Notes | USB Type-C® power delivery output specs vary, see motherboard documentation. | |
| Audio | Audio Codec | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 |
| Audio Features | High quality 120 dB SNR playback, supports 32-Bit/384 kHz playback, gold-plated audio jacks, and audio shielding. | |
| Back Panel I/O Ports | Ports | 2 x Thunderbolt™ 4, 6 x USB 10Gbps, 4 x USB 5Gbps, 2 x USB 2.0, 1 x DisplayPort, 1 x HDMI™ port, 1 x Wi-Fi module, 1 x Intel® 2.5Gb Ethernet port, 2 x audio jacks, 1 x Optical S/PDIF out port, 1 x BIOS FlashBack™ button, 1 x Clear CMOS button |
| Power Button | 1 x Power Button, 1 x Reset Button | |
| Notes | Ensure all connections are secured during setup. | |
| Internal I/O Connectors | Fan and Cooling Related | 1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header, 1 x 4-pin AIO Pump header, 5 x 4-pin Chassis Fan headers |
| Power Related | 1 x 24-pin Main Power connector, 2 x 8-pin +12V CPU Power connectors | |
| Storage Related | 1 x 6-pin SATA Power connector, 1 x 4-pin M.2 power connector | |
| Other Connectors | 1 x 20-pin System Panel header, 1 x 4-pin Speaker header, 1 x 4-pin TPM header |
